About R & D Conta Blender GMP (SCB)

Conta Blender operates on free flow principle. This unit is used for dry blending, rapid mixing of all types of free flowing powder and granules, mixing, lubrication and homogenizing of the powder and granules. It consists of octagon shaped body, rectangular central portion and top and bottom polygonal frustum.

The uniform, multidimensional arrangement of the Blender walls ensures good blending and mixing. The vessel is manufactured from stainless steel.

Make An Inquiry

Detailed Specification for R & D Conta Blender GMP (SCB)

  • Technical Specifications
  • Special Features
  • Advantages
  • Electrical Specifications
TypeSCB-24SCB-48
Gross Volume24L (12 Kg)48L (32 Kg)
Working Volume60% of Gross volume
(Designed As Per 0.5 Bulk Density)		60% of Gross volume
(Designed As Per 0.5 Bulk Density)
Product Contact PartsSS 316 LSS 316 L
Other PartsSS 304 Covered / CladdedSS 304 Covered / Cladded
Internal240 Grit Bright polished.240 Grit Bright polished.
External180 Grit Polished.180 Grit Polished.
Blender RPM02 to 3602 to 36
DischargeButterfly ValveButterfly Valve
GasketsFood Grade SiliconFood Grade Silicon
Safety GuardSS Pipe Guard Will Be Provided With Limit / Proxy Switch,
If Guard Is Open Then The Blender Will Not Run.		SS Pipe Guard Will Be Provided With Limit / Proxy Switch,
If Guard Is Open Then The Blender Will Not Run.
Motor With BrakeCrompton Greaves,
1 HP / 1440 RPM / TEFC Foot Mounted		Crompton Greaves,
2 HP / 1440 RPM / TEFC Foot Mounted
Motor For
PLC / Touch Screen		Bonfiglioli,
1 HP / 1440 RPM / TEFC Foot Mounted		Bonfiglioli,
2 HP / 1440 RPM / TEFC Foot Mounted
Reduction Gear BoxBonfiglioli MakeBonfiglioli Make
Power Supply415 V/ 50 Hz / 3 Ph / A.C.415 V/ 50 Hz / 3 Ph / A.C.
Net Weight134 Kg.170 kg.
  • All contact parts are S.S. 316L as per cGMP Standard.
  • 0° stopping for easy docking and unlocking of the bin.
  • Automatic operation of the blending cycle through pre-set timer.
  • Built in butterfly valve for at the bottom for discharge.
  • Heavy duty structure with safety railing interlock.
  • Entire working area of the blender is protected by railing, if railing will open drive will stop Immediately.
  • Short mixing & granulation time.
  • Easy to clean design.
  • Processing of different sizes of production in single equipment.
  • Dust free operation in solid dosage processing area.
  • No risk of defending on extended processing.
  • Containerized transfer of processed material avoiding manual scooping.
TypeDETAILS
Electrical MotorCG or Equivalent Make,
Only Mounted Suitably With The Machine.
Gear BoxBonfiglioli or equivalent Make
SMPSMake: Schneider
MCBMake: Schneider
Push ButtonsMake: Teknic
RelaysMake: Allen Bradley
Power / Control PanelMade from S.S.304.
All Switch Contactor Are Mounted Inside The Panel
PLC / HMI 7"
Color Touch Panel		Make: Schneider

Utility Requirement

TYPESDETAILS
Electrical Supply415 V AC, 3 phase , 50 Hz.
Foundation
Customer’s scope		If required.

Documentation

Blenders comes along with all documentation like IQ, OQ, PQ and FAT are optional at extra cost.
